ハウジングの材料: | 304ステンレス鋼 | 棒の長さ: | 490mm |
---|---|---|---|
回転方向: | 二重方向 | モーターの定常電圧: | DC12V |
ハイライト: | 歩行者の障壁のゲート,保証入口のゲート,縦のタイプされた三脚の回転木戸 |
Functions & Features
Full-automatic type
(1). Stainless steel Housing.
(2). Bi-direction pass.
(3). Arms auto drop when power off.
(4). Arms auto rise up when power on and auto stop on obstacle.
(5). Traffic light indicator.
(6). Wingen 26/Dry contact, is compatible with smart card for access control.
(7). Photoelectric inspection.
(8). If the passenger does not pass in valid time, the passage will be locked up. And the valid passing time can be set up by operator.
(9). Passenger counters (optional).
Model Item |
WJTS122 | ||
Manual, Semi or Full-automatic | Full-automatic | ||
Material of Housing | 304 Stainless Steel | ||
Thickness of Housing | 1.50mm | ||
Dimension of Housing (L×W×H mm) |
420×380×1000 | ||
Length of Pole (out of housing) | 490mm | ||
Net Weight | 50kg | ||
Max Load-bearing of Pole | 80kg | ||
Driving Force of Pole | 3kg | ||
Rotating Direction | Double Direction | ||
Power Supply | 220V±10%, 110V±10% | ||
Frequency | 50/60HZ | ||
Working Voltage of Motor | DC12V | ||
Rated Power | 50W | ||
Driving Motor | Brush DC Motor | ||
Communication Interface | RS232 standard socket/LAN socket | ||
Input Interface | DC12V electrical leveel signal, more than 10ms, or DC12V impulse signal driveing current, more 10mA | ||
Transit Speed | 20~35 persons/min | ||
Working Temperature | 15°C~55°C | ||
Working Environment | Indoor / Outdoor (Shelter) | ||
Relative Humidity | ≤90%, no condensation |
